Especificaciones:
| Model | |
| Brand | MSI |
| Model | MPG B550 GAMING PLUS |
| Supported CPU | |
| CPU Socket Type | AM4 |
| CPU Type | Supports AM4 socket 3rd Gen AMD Ryzen processors, and future AMD Ryzen processors with BIOS update |
| Chipsets | |
| Chipset | AMD B550 |
| Memory | |
| Number of Memory Slots | 4x 288pin (DDR4) |
| Memory Standard | Supports DDR4 4400+/ 4266/ 4133/ 4000/ 3866/ 3733/ 3600/ 3466/ 3200/ 3066/ 3000/ 2933/ 2800/ 2667 MHz |
| Maximum Memory Supported | 128GB |
| Channel Supported | Dual Channel |
| Expansion Slots | |
| PCI Express 4.0 x16 | 1 x PCIe 4.0/3.0 x16 slot (PCI_E1) * |
| * The supported specification depends on installed processor. | |
| PCI Express 3.0 x16 | 1 x PCIe 3.0 x16 slot (PCI_E3), supports x4 speed ** |
| ** When installing PCIe SSD in M.2_2, PCI_E3 slot will be unavailable. | |
| PCI Express x16 | 1 x PCI Express x16 |
| PCI Express x1 | 2 x PCIe 3.0 x1 slots |
| Storage Devices | |
| SATA 6Gb/s | 6 x SATA 6Gb/s |
| M.2 | 2 x M.2 slots (Key M) |
| M2_1 slot (from AMD Processor) | |
| Supports PCIe 4.0/3.0 x4 * | |
| Supports SATA 6Gb/s | |
| Supports 2242/2260/2280/22110 storage devices | |
| M2_2 slot (from AMD B550 chipset) | |
| Supports PCIe 3.0 x4 | |
| Supports 2242/2260/2280 storage devices | |
| * The supported specification depends on installed processor. | |
| SATA RAID | 0/1/10 |
| Onboard Video | |
| Onboard Video Chipset | Supported only by CPU with integrated graphic: |
| 1 x HDMI port, supports a maximum resolution of 4096×2160 @24Hz | |
| 1 x DisplayPort, supports a maximum resolution of 4096×2160 @60Hz | |
| Maximum shared memory of 16GB | |
| * Available for the processor with integrated graphics. | |
| Onboard Audio | |
| Audio Chipset | Realtek ALC892 |
| Audio Channels | 7.1-Channel High Definition Audio |
| Supports S/PDIF output | |
| Onboard LAN | |
| LAN Chipset | Realtek RTL8111H |
| Max LAN Speed | 1Gbps |
| Rear Panel Ports | |
| Back I/O Ports | 4 x USB 3.1 Gen 1 |
| USB 3.0 | 4 x USB 3.0 |
| Internal I/O Connectors | |
| Onboard USB | 1 x USB 3.2 Gen 1 5Gbps Type-C port |
| 1 x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) | |
| 2 x USB 2.0 connectors (supports additional 4 USB 2.0 ports) | |
| Other Connectors | 1 x 4-pin CPU fan connector |
| 1 x 4-pin water-pump fan connector | |
| 6 x 4-pin system fan connectors | |
| 1 x Front panel audio connector | |
| 2 x System panel connectors | |
| 1 x Chassis Intrusion connector | |
| 1 x 4-pin RGB LED connector | |
| 2 x 3-pin RAINBOW LED connectors | |
| 1 x TPM module connector | |
| 1 x Clear CMOS jumper | |
| Physical Spec | |
| Form Factor | ATX |
| LED Lighting | RGB |
| Dimensions (W x L) | 12.0″ x 9.6″ |
| Power Pin | 1 x 24-pin ATX main power connector |
| 1 x 8-pin ATX 12V power connector | |
| Windows 11 Compatibility | |
| Windows 11 | Supported |
| Features | |
| Features | Support for 3rd Gen AMD Ryzen Processors and future AMD Ryzen processors with BIOS update |
| Supports DDR4 Memory, up to 4400(OC) MHz | |
| Lightning Fast Game experience: PCIe 4.0, Lightning Gen 4 x4 M.2 with M.2 Shield Frozr, AMD Turbo USB 3.2 GEN 2 | |
| Enhanced Power Design: Core Boost, Digital PWM IC, 2oz Thickened Copper PCB, DDR4 Boost | |
| Premium Thermal Solution: Extended Heatsink Design and M.2 Shield Frozr are built for high performance system and non-stop gaming experience | |
| Pre-installed I/O Shielding: Better EMI protection and more convenience for installation | |
| Flash BIOS Button with Optmized ClearCMOS Function: Simply use a USB key to flash any BIOS within seconds. Restore the BIOS to the default settings without any additional actions | |
| Audio Boost: Reward your ears with studio grade sound quality | |
Para usar procesadores Ryzen de la serie 5000, es necesario actualizar la bios de la placa madre, esto lo puede realizar el cliente de manera fácil mediante puerto USB ubicado en la parte posterior de la placa.
